產品名稱：法國SAFT電池 產品介紹： 法國SAFT電池 |
詳細介紹
SAFT
Lithium-sulfur dioxide (Li-SO2) : LO/G cell ranges 產品詳細資料請點擊！
| G04/3 | G06/2 | G32/3 | G36/2 | LO34SX | |
| Size | ½ AA | AA | 2/3 A | "Long" A | 1/3 C |
| Open Circuit Voltage | 3 V | 3 V | 3 V | 3 V | 3 V |
| Nominal Voltage | 2.8 V | 2.8 V | 2.8 V | 2.8 V | 2.9 V |
| Nominal capacity (drain) | 0.45 Ah (50 mA) | 0.95 Ah (80 mA) | 0.8 Ah (80 mA) | 1.7 Ah (80 mA) | 0.86 Ah (80 mA) |
| Max. recom. Cont. Current | 0.25 A | 0.5 A | 0.75 A | 1.5 A | 1.0 A |
| Operating temperature range | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* |
| Outside diameter max | 14.2 mm | 14.2 mm | 16.3 mm | 16.3 mm | 25.9 mm |
| Length max | 27.9 mm | 50.3 mm | 34.5 mm | 57.7 mm | 20.3 mm |
| Weight | 8 g | 15 g | 12 g | 18 g | 18 g |
| Transport | Non restricted | Non restricted | Non restricted | Non restricted | Non restricted |
|
|
LO35SX | G52/3 | LO29SHX | G54/3 | LO43SHX |
| Size | 2/3 C | C | C | 5/4 C | 5/4 C |
| Open Circuit Voltage | 3 V | 3 V | 3 V | 3 V | 3 V |
| Nominal Voltage | 2.8 V | 2.8 V | 2.8 V | 2.8 V | 2.8 V |
| Nominal capacity (drain) | 2.2 Ah (650 mA) | 3.2 Ah (1.0 A) | 3.75 Ah (0.25 A) | 5.0 Ah (0.2 A) | 5.0 Ah (0.2 A) |
| Max. recom. Cont. Current | 2.0 A | 2.5 A | 2.5 A | 2.5 A | 2.5 A |
| Operating temperature range | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* |
| Outside diameter max | 25.9 mm | 25.6 mm | 25.6 mm | 25.6 mm | 26.0 mm |
| Length max | 35.9 mm | 49.5 mm | 50.4 mm | 60.2 mm | 59.2 mm |
| Weight | 30 g | 47 g | 40 g | 58 g | 53 g |
| Transport | Non restricted | Class 9 | Class 9 | Class 9 | Class 9 |
| LO40SX | LO30SHX | G26 | LO26SX | LO26SHX | |
| Size | 2/3 "Thin" D | "Thin" D | D | D | D |
| Open Circuit Voltage | 3 V | 3 V | 3.0 V | 3.0 V | 3.0 V |
| Nominal Voltage | 2.8 V | 2.8 V | 2.8 V | 2.8 V | 2.8 V |
| Nominal capacity (drain) | 3.5 Ah (0.12 A) | 5.75 Ah (0.2 A) | 7.75 Ah (0.25 A) | 7.75 Ah (0.25 A) | 7.5 Ah (0.25 A) |
| Max. recom. Cont. Current | 2.0 A | 3.0 A | 2.5 A | 2.5 A | 4.0 A |
| Operating temperature range | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* |
| Outside diameter max | 28.95 mm | 29.1 mm | 34.5 mm | 34.2 mm | 34.2 mm |
| Length max | 42.29 mm | 59.9 mm | 59.8 mm | 59.3 mm | 59.3 mm |
| Weight | 40 g | 63 g | 85 g | 85 g | 85 g |
| Transport | Class 9 | Class 9 | Class 9 | Class 9 | Class 9 |
|
|
LO26SXC | LO25SX | LO39SHX | G22/6 | G62/1 |
| Size | D | "Fat" D | F | DD | "Long Fat DD" |
| Open Circuit Voltage | 3.0 V | 3 V | 3 V | 3 V | 3 V |
| Nominal Voltage | 2.8 V | 2.8 V | 2.8 V | 2.8 V | 2.8 V |
| Nominal capacity (drain) | 9.2 Ah (0.25 A) | 8.0 Ah (0.27 A) | 11.5 Ah (1 A) | 16.5 Ah (0.5 A) | 34.0 Ah (1.0 A) |
| Max. recom. Cont. Current | 2.5 A | 2.5 A | 3.0 A | 3.0 A | 3.0 A |
| Operating temperature range | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C* | -60/+70°C * |
| Outside diameter max | 34.2 mm | 39.5 mm | 31.9 mm | 33.3 mm | 41.7 mm |
| Length max | 59.3 mm | 50.3 mm | 100.3 mm | 120.6 mm | 141 mm |
| Weight | 85 g | 96 g | 125 g | 175 g | 300 g |
| Transport | Class 9 | Class 9 | Class 9 | Class 9 | Class 9 |
